Motors & Generators
High Temperature and high performance Insulation
APICAL® Polyimide Film Is the Right Choice.
APICAL® Polyimide: The Right Choice for Motors
In demanding applications, such as locomotive traction motors, temperatures can soar to 400C or 500C in a short period of time. High-performance motors, generators, and transformers often operate under extremely harsh conditions. APICAL® Polyimide Film is the right choice for these applications, easily enduring high heat without loss of mechanical or dielectric strength.
Advantages of APICAL® Polyimide for Motors
Traditionally, mica or glass were the primary materials used for insulation. However, APICAL® Polyimide can be wrapped thinner and tighter in motor windings, allowing for the use of thicker, higher current-carrying conductors. This advancement makes APICAL® Polyimide the ideal polyimide for motors, enhancing their efficiency and performance.
Versatile Applications
APICAL® Polyimide Film is utilized in various demanding environments beyond locomotives. You’ll find it in aircraft engines, mining equipment, and within the utility and petroleum industries. Its versatility makes it the preferred polyimide for motors. Typical applications include armature coil insulation, rotor and stator slot liner insulation, and magnet and thermocouple wire insulation. This wide range of uses underscores the effectiveness of APICAL® Polyimide as the go-to polyimide for motors in high-performance scenarios.
Critical Properties for Motor and Generator Insulation
The critical properties of APICAL® Polyimide that make it ideal for motor and generator insulation include:
- Broad Temperature Cycling Range: With a range from -269°C to 400°C, APICAL® Polyimide can withstand extreme temperature variations.
- Superior Dielectric Properties: It boasts a dielectric strength of 7,800v/mil, ensuring reliable electrical insulation.
- Outstanding Mechanical Durability: APICAL® Polyimide is known for its exceptional toughness, maintaining integrity under mechanical stress.
- High Thermal Index: With a thermal index of 240°C for electrical applications, it performs reliably in high-temperature environments.
- Good Chemical Resistance: It resists degradation from various chemicals, adding to its longevity and reliability.
Why Choose APICAL Polyimide For Motors?
When it comes to high-performance insulation, especially for applications requiring polyimide for motors, APICAL® Polyimide Film stands out. Its ability to endure high temperatures, provide superior dielectric properties, and maintain mechanical durability makes it the top choice for motor, generator, and transformer insulation. Choose APICAL® Polyimide for motors to ensure unmatched performance and reliability in your high-temperature applications.
Ask The Engineers
Here’s your chance to ask Kaneka Engineers questions about APICAL® Polyimide Film and its applications. Use it as an open exchange of ideas and questions about polyimide applications, challenges, and innovations.
More Information
Quality
Industries who depend upon APICAL® Polyimide Film benefit not only from a carefully designed product, but from the process behind it as well. Unlike many film manufacturers, APICAL® Polyimide process technology is driven by quality not speed.
Performance
In spite of being lighter in weight than many of the materials it has replaced, the overall performance of APICAL® Polyimide surpasses them. Its high degree of dimensional stability allows it to be wrapped tightly for applications where space is a premium. It is tough, highly resistant to tearing, abrasion and puncture.
Technical Data
APICAL® Polyimide Films possess an excellent balance of physical, thermal, electrical, and chemical properties over a wide range of temperatures for flexible printed circuits, tape automated bonding, motor generator insulation, wire and cable insulation, pressure sensitive tape and other uses.
