APICAL® Polyimide CR
Type CR Polyimide Film
APICAL® Polyimide Film Is the Right Choice.
APICAL® Corona Resistant Polyimide 110CR and L50CR11 are high temperature Polyimide Films. These CR films have excellent thermal and electrical stability over the long life of any motor.
APICAL® 110CR and L50CR11 is designed to withstand the compounding conditions and form strong interfacial bonding with many materials. The polymer will remain stable during extended high temperature continuous use conditions.
Applications
- Motors
- Generators
- Transformers
Attributes
- Excellent thermal and electrical stability
- Excellent adhesion to copper
- Excellent corona resistant stability
Polyimide Films
Ask The Engineers
Typical Properties 110CR@ 27um (1.10 mil)
Electrical
| Value | Test Method | |
|---|---|---|
| Corona Resistance hrs | >100,000 | IEC 60343 |
| Dielectric Strength v/mil | 6000 | ASTM D149 |
| Volume Resistivity ohm/cm | 4.5×1018 | ASTM D257 |
| Surface Resitivity ohm/sq | 1.5×1016 | ASTM D257 |
| Dielectric Constant | 2.77 | IPC TM 650 |
| Dissipation Factor 1MHz | 0.000024 | IPC TM 650 |
Mechanical
| Value | Test Method | |
|---|---|---|
| Tensile psi (MPa) | 40,000 (276) | ASTM D882 |
| Elongation % | 98 | ASTM D882 |
| Modulus ksi | 560 | ASTM D882 |
| Tear Propagation | 0.9 | ASTM D1922 |
| Tear Initial | 7.1 | ASTM D1004 |
| Yield g/m2 | 44.88 | Kaneka Method |
| Density | 1.57 | ASTM D1505 |
Downloads
More Information
Quality
Industries who depend upon APICAL® Polyimide Film benefit not only from a carefully designed product, but from the process behind it as well. Unlike many film manufacturers, APICAL® Polyimide process technology is driven by quality not speed.
Performance
In spite of being lighter in weight than many of the materials it has replaced, the overall performance of APICAL® Polyimide surpasses them. Its high degree of dimensional stability allows it to be wrapped tightly for applications where space is a premium. It is tough, highly resistant to tearing, abrasion and puncture.
